Product Summary

The rd70hvf1 is an IGBT module. Application areas of the rd70hvf1 include AC motor controllers, DC motor controllers, Battery DC power supplies, DC power supplies for control panels, and other general DC power equipment.

Parametrics

rd70hvf1 absolute maximum ratings: (1)Repetitive peak reverse voltage: 400V 800V 1200V 1600V ; (2)Non-repetitive peak reverse voltage: 480V 960V 1350V 1700V; (3)Reverse DC voltage: 320V 640V 960V 1280V.

Features

rd70hvf1 features: (1)Repetitive reverse current: (1)Repetitive reverse current: 30mA; (2)Forward voltage: 1.35V; (3)Thermal resistance: 0.22 C/W; (4)Contact thermal resistance: 0.1°C/W; (5)Insulation resistance: 10MΩ.

Diagrams

rd70hvf1 block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
RD70HVF1
RD70HVF1
Other

Data Sheet
Negotiable
