Product Summary

The MOC3163 is a 6-pin DIP zero-cross phototriac driver optocoupler. It consists of a GaAs infrared emitting diode optically coupled to a monolithic silicon detector performing the function of a zero voltage crossing bilateral triac driver. The MOC3163 is designed for use with a triac in the interface of logic systems to equipment powered from 115/240 VAC lines, such as solid-state relays, industrial controls, motors, solenoids and consumer appliances, etc. The applications of the MOC3163 are Solenoid/valve controls, Static power switches, Temperature controls, AC motor starters, Lighting controls, AC motor drives, E.M. contactors, Solid state relays.

Parametrics

MOC3163 absolute maximum ratings: (1)Storage Temperature:-40 to +150℃; (2)Operating Temperature:-40 to +85℃; (3)Lead Solder Temperature:260℃ for 10 sec; (4)Junction Temperature Range:-40 to +100℃; (5)Isolation Surge Voltage:7500 Vac(pk); (6)Total Device Power Dissipation:250 mW.

Features

MOC3163 features: (1)Simplifies logic control of 115/240 VAC power; (2)Zero voltage crossing; (3)dv/dt of 600 V/ms guaranteed; (4)VDE recognized (File # 94766), ordering option V; (5)Underwriters Laboratories (UL) recognized (File #E90700, volume 2).

Diagrams

MOC3163 diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MOC3163FR2M
MOC3163FR2M

Fairchild Semiconductor

Triac & SCR Output Optocouplers 6-Pin Optocoupler ZC Triac Driver 600V

Data Sheet

Negotiable
MOC3163FVM
MOC3163FVM

Fairchild Semiconductor

Triac & SCR Output Optocouplers 6-Pin Optocoupler ZC Triac Driver 600V

Data Sheet

Negotiable
MOC3163M
MOC3163M

Fairchild Semiconductor

Triac & SCR Output Optocouplers 600V Optocoupler Triac Driver ZC

Data Sheet

0-1: $1.15
1-25: $1.03
25-100: $0.92
100-250: $0.82
MOC3163-M
MOC3163-M

Other


Data Sheet

Negotiable
MOC3163M_Q
MOC3163M_Q

Fairchild Semiconductor

Triac & SCR Output Optocouplers 600V Optocoupler Triac Driver ZC

Data Sheet

Negotiable
MOC3163SM
MOC3163SM

Fairchild Semiconductor

Triac & SCR Output Optocouplers 6-Pin Optocoupler ZC Triac Driver 600V

Data Sheet

0-570: $0.72
570-1000: $0.59
1000-2000: $0.55
2000-5000: $0.53
MOC3163SR2M
MOC3163SR2M

Fairchild Semiconductor

Triac & SCR Output Optocouplers 6-Pin Optocoupler ZC Triac Driver 600V

Data Sheet

0-500: $0.73
500-1000: $0.60
1000-2000: $0.56
2000-5000: $0.54
MOC3163SR2VM
MOC3163SR2VM

Fairchild Semiconductor

Triac & SCR Output Optocouplers 6-Pin Optocoupler ZC Triac Driver 600V

Data Sheet

0-1: $1.29
1-25: $1.04
25-100: $0.94
100-250: $0.83
