Product Summary
The ADM489ARZ-REEL is a low power differential line transceiver suitable for communication on multipoint bus transmission lines. The device is intended for balanced data transmission and comply with both EIA Standards RS-485 and RS-422. The ADM489ARZ-REEL contains a single differential line driver and a single differential line receiver making the device suitable for full duplex data transfer. The ADM489ARZ-REEL contains an additional receiver and driver enable control. The input impedance is 12 kΩ, allowing 32 transceivers to be connected on the bus. The applications of the ADM489ARZ-REEL include Low Power RS-485 Systems, DTE-DCE Interface, Packet Switching, Local Area Networks, Data Concentration, Data Multiplexers and Integrated Services Digital Network (ISDN).
Parametrics
ADM489ARZ-REEL absolute maximum ratings: (1)VCC: +7 V; (2)Driver Input (DI): –0.3 V to VCC + 0.3 V; (3)Control Inputs (DE, RE):–0.3 V to VCC + 0.3 V; (4)Receiver Inputs (A, B):–14 V to +14 V; (5)Driver Outputs: –14 V to +12.5 V; (6)Receiver Output:–0.5 V to VCC + 0.5 V; (7)Power Dissipation: 700 mW; (8)θJA, Thermal Impedance: 120℃/W; (9)Operating Temperature Range, Industrial (A Version): –40 to +85℃; (10)Storage Temperature Range: –65 to +150℃; (11)Lead Temperature (Soldering, 10 secs): +300℃; (12)Vapor Phase (60 secs): +215℃; (13)Infrared (15 secs): +220℃; (14)ESD Rating, MIL-STD-883B: 4 kV; (15)EFT Rating, IEC1000-4-4: 2 kV.
Features
ADM489ARZ-REEL features: (1)Meets EIA RS-485 Standard; (2)250 kbps Data Rate; (3)Single +5 V ± 10% Supply; (4)–7 V to +12 V Bus Common-Mode Range; (5)12 kΩ Input Impedance; (6)2 kV EFT Protection Meets IEC1000-4-4; (7)High EM Immunity Meets IEC1000-4-3; (8)Reduced Slew Rate for Low EM Interference; (9)Short Circuit Protection; (10)Excellent Noise Immunity; (11)30 μA Supply Current.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADM489ARZ-REEL |
|
IC TXRX RS-485 DIFF LP 14SOIC |
Data Sheet |
|
|
||||||
|
ADM489ARZ-REEL7 |
|
IC TXRX RS-485 DIFF LP 14SOIC |
Data Sheet |
|
|
||||||
