Product Summary
The 4n33 is a general purpose 6-pin photodarlington optocoupler. The 4n33 has a gallium arsenide infrared emitter optically coupled to a silicon planar photodarlington. The applications of the 4n33 include Low power logic circuits, Telecommunications equipment, Portable electronics, Solid state relays, Interfacing coupling systems of different potentials and impedances.
Parametrics
4n33 absolute maximum ratings: (1)Storage Temperature, TSTG: -55 to +150℃; (2)Operating Temperature, TOPR: -55 to +100℃; (3)Lead Solder Temperature, TSOL: 260 for 10 sec℃; (4)Total Device Power Dissipation @ TA = 25℃, PD: 250 mW; Derate above 25℃, PD: 3.3 mW/℃; (5)Continuous Forward Current, IF: 80 mA; (6)Reverse VoltageVR: 3 V; (7)Forward Current - Peak (300μs, 2% Duty Cycle), IF(pk): 3.0 A; (8)LED Power Dissipation @ TA= 25℃, PD: 150 mW; Derate above 25℃, PD: 2.0 mW/℃; (9)Collector-Emitter Breakdown Voltage, BVCEO: 30 V; (10)Collector-Base Breakdown Voltage, BVCBO: 30 V; (11)Emitter-Collector Breakdown Voltage, BVCBO: 5 V; (12)Detector Power Dissipation @ TA= 25℃, PD: 150 mW; Derate above 25℃, IC: 2.0 mW/℃; (13)Continuous Collector Current, IC: 150 mA.
Features
4n33 features: (1)High sensitivity to low input drive current; (2)Meets or exceeds all JEDEC Registered Specifications; (3)VDE 0884 approval available as a test option-add option .300. (e.g., 4N29.300).
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 4N33 |
Vishay Semiconductors |
Transistor Output Optocouplers Photodarlington Out |
Data Sheet |
|
|
||||||||||||
 |
4N33(SHORT) |
|
PHOTOCOUPLER DARL TRANS-OUT 6DIP |
Data Sheet |
Negotiable |
|
||||||||||||
|
4N33(SHORT,F) |
Toshiba |
Transistor Output Optocouplers TR JEDIC EQUIL |
Data Sheet |
|
|
||||||||||||
|
4N33_Q |
Fairchild Semiconductor |
Transistor Output Optocouplers DIP-6 PHOTO DARL |
Data Sheet |
Negotiable |
|
||||||||||||
|
4N33300 |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler Photodarlington |
Data Sheet |
Negotiable |
|
||||||||||||
|
4N33300W |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler Photodarlington |
Data Sheet |
Negotiable |
|
||||||||||||
|
4N333S |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler SM-DIP6 Photodarlington |
Data Sheet |
Negotiable |
|
||||||||||||
|
4N333SD |
Fairchild Semiconductor |
Transistor Output Optocouplers Optocoupler SM-DIP6 Photodarlington |
Data Sheet |
Negotiable |
|
||||||||||||
