aqw210hlax

photoMOS relay, 120MA, 8SMD, 350V, aqw210hlax, Panasonic

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.75~1.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.75~1.00

PartNumber:: aqw210hlax

Brand:: Panasonic Semiconductor - Panasonic | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Luisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-11

From Other Seller

Part Number:aqw210hlax
US $0.75 - 1.00
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The aqw210hlax is a photoMOS relay. It is used in Telephone equipment, Modem.

Parametrics

aqw210hlax absolute maximum ratings: (1)LED forward current IF: 50mA; (2)LED reverse voltage VR: 3V; (3)Peak forward current IFP: 1A; (4)Power dissipation Pin: 75mW; (5)Load voltage (peak AC) VL: 350V; (6)Continuous load current IL: 0.1A; (7)Power dissipation Pout: 800mW; (8)Total power dissipation PT: 850mW; (9)I/O isolation voltage Viso: 5000V AC; (10)Operating temperature Topr: –40℃ to +85℃; (11)Storage temperature Tstg: –40℃ to +100℃.

Features

aqw210hlax features: (1)Current Limit Function; (2)Enhancing the capability of surge resistance between output terminals; (3)Reinforced insulation 5,000 V type; (4)Compact 8-pin DIP size; (5)Applicable for 2 Form A use as well as two independent 1 Form A use; (6)Controls low-level analog signals; (7)High sensitivity, high speed response; (8)Low-level off state leakage current.
