Product Summary
The opa2343ea serie rail-to-rail CMOS operational amplifier is designed for low-cost, miniature applications. The opa2343ea is optimized for low-voltage, single-supply operation. Rail-to-rail input/output and high-speed operation make them ideal for driving sampling Analog-to-Digital (A/D) converters. The opa2343ea is also well suited for general-purpose and audio applications as well as providing I/V conversion at the output of Digital-to-Analog (D/A) converters. Single, dual, and quad versions have identical specifications for design flexibility.
Parametrics
opa2343ea absolute maximum ratings: (1)Supply Voltage : 7.5V; (2)Signal Input Terminals, Voltage: (V–) –0.5V to (V+) +0.5V; (3)Current: 10mA; (4)Output Short-Circuit: Continuous; (5)Operating Temperature : –55°C to +125°C; (6)Storage Temperature: –65°C to +150°C; (7)Junction Temperature : 150°C; (8)Lead Temperature (soldering, 10s): 300°C.
Features
opa2343ea features: (1)rail-to-rail input/output; (2)micro size packages; (3)wide bandwidth: 5.5mhz; (4)high slew rate: 6v/μs; (5)low thd+noise: 0.0007% (f = 1khz); (6)low quiescent current: 850μa/chan; (7)single, dual, and quad versions.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
OPA2343EA |
Other |
Data Sheet |
Negotiable |
|
||||||||||||||
OPA2343EA/250 |
Texas Instruments |
Operational Amplifiers - Op Amps Single-Supply Rail-to-Rail |
Data Sheet |
|
|
|||||||||||||
OPA2343EA/2K5 |
Texas Instruments |
Operational Amplifiers - Op Amps Single-Supply Rail-to-Rail |
Data Sheet |
|
|
|||||||||||||
OPA2343EA/250G4 |
Texas Instruments |
Operational Amplifiers - Op Amps Single-Supply Rail-to-Rail |
Data Sheet |
|
|
|||||||||||||
OPA2343EA/2K5G4 |
Texas Instruments |
Operational Amplifiers - Op Amps Single-Supply Rail-to-Rail |
Data Sheet |
|
|
