Product Summary

The SFH6286-2T is a Phototransistor Output, Optocoupler. The SFH6286-2T is a high current transfer ratio, low coupling capacitance and high isolation voltage. These couplers have a GaAs infrared emitting diode, which is optically coupled to a silicon planar phototransistor detector, and is incorporated in a plastic DIP-4 or SMD package. The coupling devices are designed for signal transmission between two electrically separated circuits.Application areas of the SFH6286-2T include Telecom, Industrial Controls, Battery Powered Equipment, Office Machines.

Parametrics

SFH6286-2T absolute maximum ratings: (1)DC Forward current: ±50mA; (2)Surge forward current: ±2.5 A; (3)Collector-emitter voltage: 55V; (4)Emitter-collector voltage: 7.0V; (5)Collector current: IC 50mA IC 100mA; (6)Power dissipation: 150mW.

Features

SFH6286-2T features: (1)High Common-mode Interference Immunity; (2)Isolation Test Voltage, 5300 VRMS; (3)Low Coupling Capacitance; (4)Good CTR Linearity Depending on Forward Current; (5)Low CTR Degradation; (6)High Collector-emitter Voltage, VCEO = 55 V; (7)Lead (Pb)-free component; (8)Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC.

Diagrams

SFH6286-2T block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
SFH6286-2T
SFH6286-2T

Vishay Semiconductors

Transistor Output Optocouplers Phototransistor Out AC-In CTR>63-200%

Data Sheet

0-1: $0.49
1-10: $0.44
10-100: $0.39
100-250: $0.36
