Product Summary
The cny17f-4m is a phototransistor optocoupler. It consists of a Gallium Arsenide IRED coupled with an NPN phototransistor in a dual in-line package. The applications of the cny17f-4m include: power supply regulators, digital logic inputs, microprocessor inputs, appliance sensor systems, industrial controls.
Parametrics
cny17f-4m absolute maximum ratings: (1)TSTG storage temperature: -40 to +150℃; (2)TOPR operating temperature: -40 to +100℃; (3)TJ junction temperature: -40 to +125℃; (4)TSOL lead solder temperature: 260℃ for 10sec; (5)PD total device power dissipation@25℃(LED plus detector): 250mW, derate lineraly form 25℃: 2.94mW/℃; (6)IF continuous forward current: 60mA; (7)VR reverse voltage: 6V; (8)IF(pk) forward current-peak: 1.5A.
Features
cny17f-4m features: (1)UL recognized; (2)VDE recognized; (3)Current transfer ratio in select groups; (4)High BVCEO: 70V minimum; (5)Closely matched current transfer retio(CTR)minimizes unit-to-unit variation; (6)Very low coupled capacitance along with no chip to pin 6 base connection for minimum noise susceptability.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CNY17F-4M |
Everlight |
Transistor Output Optocouplers 160-320CTR 5000Vrms -55 to +110 Op Temp |
Data Sheet |
|
|
||||||||||||
 |
CNY17F-4M-V |
Everlight |
Transistor Output Optocouplers 160-320CTR 5000Vrms -55 to +110 Op Temp |
Data Sheet |
|
|
||||||||||||
