Product Summary
The bc807-70 is a pnp surface mount transistor. The bc807-70 is UL Flammability Classification Rating 94V-0.Moisture Sensitivity: Level 1 per J-STD-020C.
Parametrics
bc807-70 absolute maximum ratings: (1)Collector-Emitter Voltage:-45 V; (2)Emitter-Base Voltage:-5.0 V; (3)Collector Current:-500 mA; (4)Peak Collector Current:-1000 mA; (5)Peak Emitter Current:-1000 mA; (6)Power Dissipation at TSB = 50°C (Note 3):200 mW; (7)Thermal Resistance, Junction to Ambient Air (Note 3):625 °C/W; (8)Operating and Storage Temperature Range:-65 to +150 °C.
Features
bc807-70 features: (1)Ideally Suited for Automatic Insertion; (2)Epitaxial Planar Die Construction; (3)For Switching, AF Driver and Amplifier Applications; (4)Complementary NPN Types Available; (5)Lead Free By Design/RoHS Compliant (Note 1); (6)"Green" Device (Note 2).
