ad811anz

wideband current feedback operational amplifier, 120 MHz, 150 Ω, dip

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.00~4.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.00~4.00

PartNumber:: ad811anz

Brand:: Analog Devices - ADI | Pack: DIP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Luisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-23

From Other Seller

Part Number:ad811anz
US $3.00 - 4.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The ad811anz is a wideband current feedback operational amplifier, the ad811anz is optimized for broadcast-quality video systems. The −3 dB bandwidth of 120 MHz at a gain of +2 and the differential gain and phase of 0.01% and 0.01° (RL = 150 Ω) make the ad811anz is an excellent choice for all video systems. The ad811anz is designed to meet a stringent 0.1 dB gain flatness specification to a bandwidth of 35 MHz (G = +2) in addition to low differential gain and phase errors. Application areas of the ad811anz include Video crosspoint switchers, multimedia broadcast systems, HDTV compatible systems, Video line drivers, distribution amplifiers, ADC/DAC buffers, DC restoration circuits.

Parametrics

ad811anz absolute maximum ratings: (1)Supply Voltage:±18 V; (2)AD811JR Grade Only: ±12 V; (3)Internal Power Dissipation: Observe Derating Curves; (4)8-Lead PDIP Package:θJA = 90°C/ W; (5)8-Lead CERDIP Package:θJA = 110°C/W; (6)8-Lead SOIC Package:θJA = 155°C/W; (7)16-Lead SOIC Package: θJA = 85°C/W; (8)20-Lead SOIC Package:θJA = 80°C/W; (9)20-Lead LCC Package:θJA = 70°C/W; (10)Storage Temperature Range (Q, E): -65°C to +150°C; (11)Storage Temperature Range (N, R): -65°C to +125°C.

Features

ad811anz features: (1)140 MHz bandwidth (3 dB, G = +1); (2)120 MHz bandwidth (3 dB, G = +2); (3)35 MHz bandwidth (0.1 dB, G = +2); (4)2500 V/μs slew rate; (5)25 ns settling time to 0.1% (for a 2 V step); (6)65 ns settling time to 0.01% (for a 10 V step); (7)Excellent video performance (RL =150 Ω); (8)0.01% differential gain, 0.01° differential phase; (9)Low distortion: THD = .74 dB @ 10 MHz; (10)Excellent dc precision: 3 mV max input offset voltage; (11)Flexible operation; (12)Specified for ±5 V and ±15 V operation; (13)±2.3 V output swing into a 75 Ω load (VS = ±5 V).
