AT88SC0204C

high-performance secure memory, 2KBIT, 1.5MHZ, 2.7V to 5.5V, SOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.10~1.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.10~1.30

PartNumber:: AT88SC0204C

Brand:: ATMEL Corporation - ATMEL | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Luisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-12

From Other Seller

Part Number:AT88SC0204C
US $1.10 - 1.30
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
HCPL-7800A

US $2.50 - 4.10 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT88SC0204C is a high-performance secure memory providing 2Kbits of user memory with advanced security and cryptographic features built in. The AT88SC0204C is divided into four 64-byte zones, each of which may be individually set with different security access rights or effectively combined together to provide space for one to four data files.

Parametrics

AT88SC0204C absolute maximum ratings: (1)Operating Temperature: -40℃ to +85℃; (2)Storage Temperature: -65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground: -0.7 to Vcc +0.7V; (4)Maximum Operating Voltage: 6.0V; (5)DC Output Current: 5.0 mA.

Features

AT88SC0204C features: (1)One of a Family of Devices with User Memories from 1-Kbit to 256-Kbits; (2)2-Kbit (256-byte) EEPROM User Memory; (3)2-Kbit Configuration Zone: 37-byte OTP Area for User-defined Codes; 160-byte Area for User-defined Keys and Passwords; (4)High Security Features: 64-bit Mutual Authentication Protocol (Under License of ELVA); Encrypted checksum; Stream Encryption; Four Key Sets for Authentication and Encryption; Eight Sets of Two 24-bit Passwords; Anti-Tearing Function; Voltage and Frequency Monitors.
