Product Summary

The AQV204A is a PhotoMOS relay. It is used in High-speed inspection machines, Telephone equipment, Data communication equipment, Computer.

Parametrics

AQV204A absolute maxing ratings: (1)LED forward current IF: 50mA; (2)LED reverse voltage VR: 6V; (3)Peak forward current IFP: 1A; (4)Power dissipation Pin: 150mW; (5)Load voltage (peak AC) VL: 400 V; (6)Continuous load current IL :0.18 A; (7)Peak load current Ipeak: 0.15 A; (8)Power dissipation Pout: 360mW; (9)Total power dissipation PT: 410mW; (10)I/O isolation voltage Viso: 1500 V AC; (11)Temperature limits Operating Topr: –40℃ to +85℃; Storage Tstg: –40℃ to +100℃.

Features

AQV204A features: (1)Controls low-level analog signals; (2)Control with low-level input signals; (3)Controls various types of loads such as relays, motors, lamps and solenoids.; (4)Optical coupling for extremely high isolation; (5)Eliminates the need for a counter electromotive force protection diode in the drive circuits on the input side; (6)Stable on resistance; (7)Low-level off state leakage current; (8)Eliminates the need for a power supply to drive the power MOSFET; (9)Low thermal electromotive force.

Diagrams

AQV204A diagram
