AT24C256N

2-Wire Serial EEPROM, 256KBIT, 1MHZ, 3.3V/5V, 8-Pin SOIC, AT24C256N

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.58~0.68 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.58~0.68

PartNumber:: AT24C256N

Brand:: ATMEL Corporation - ATMEL | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Luisa's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-12

From Other Seller

Part Number:AT24C256N
US $0.58 - 0.68
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C256N is a 2-Wire Serial EEPROM. It provides 131,072/262,144 bits of serial electrically erasable and programmable read only memory (EEPROM) organized as 16,384/32,768 words of 8 bits each. The AT24C256N cascadable feature allows up to 4 devices to share a common 2-wire bus. The device is optimized for use in many industrial and commercial applications where low power and low voltage operation are essential. The AT24C256N is available in space-saving 8-pin JEDEC PDIP. In addition, the entire family is available in 5.0V (4.5V to 5.5V) version.

Parametrics

AT24C256N absolute maximum ratings: (1)Storage Temperature: -65℃ to +150℃; (2)Voltage on Any Pin with Respect to Ground: -1.0V to +7.0V; (3)Maximum Operating Voltage: 6.25V; (4)DC Output Current: 5.0 mA; (5)Operating Temperature: -55℃ to +125℃.

Features

AT24C256N features: (1)Internally Organized 16,384 x 8 and 32,768 x 8; (2)2-Wire Serial Interface; (3)Schmitt Trigger, Filtered Inputs for Noise Suppression; (4)Bidirectional Data Transfer Protocol; (5)1 MHz (5V), 400 kHz (2.7V) and 100 kHz (1.8V) Compatibility; (6)Write Protect Pin for Hardware and Software Data Protection; (7)64-Byte Page Write Mode (Partial Page Writes Allowed); (8)Self-Timed Write Cycle (5 ms typical); (9)High Reliability; (10)Automotive Grade and Extended Temperature Devices Available; (11)8-Pin JEDEC PDIP, 8-Pin JEDEC and EIAJ SOIC, 14-Pin TSSOP, and 8-Pin Leadless Array Packages.
